●General Information
There are two kinds of unloading device, pneumatic one and manual one. The side and bottom unloading device are mainly used for material unloading in bulk cement silo. It can pneumatic control and manual control, unload evenly, simple structure, convenient operation.
●Technical Parameters
Name | Side Unloader | Bottom Unloader | Pneumatic Single Nozzle Bottom | Manual Single Nozzle Bottom | Pneumatic Double Nozzle Bottom | ||||||
Unload Ability t/h | 20-50 | 20-50 | 20-50 | 80-100 | 80-100 | ||||||
Unload Hole Inner Diameter(mm) | Φ60Φ80Φ100 | manual single nozzle | Φ80Φ100 | Φ150 | Φ150 | ||||||
Working Pressure(kg/cm2) | 2.5 | 2.5 | 2.5 | 2.5 | 2.5 | ||||||
Average Air in need(m3/t) | 1 | 1 | 1 | 1 | 1 | ||||||
Corner Angle | 90°180° | 90°180° | 90°180° | 90°180° |
