Distributor

Raw Material Distributor




General Information
Raw material distributor is a pneumatic device for the cement industry. It is mainly applicable for the dry powdery material and distribution in the Conveyor and on the top of the silo. According to the produce process the distributor could use 2 nozzles, 6 nozzles, 8 nozzles and the nozzle’s angle could range from 6° to 14°. Raw material distributor could be used for cement and raw material's distribution in large, middle and small cement plant.
●Technical Parameters


Type(mm)
Material Conveying Ability (t/h)
Air Pressure (mmH2O)
Blowing Rate (m3/min)
Φ800
6 nozzles
<120
700
2
8 nozzles
<140
2.5
Φ1000
6 nozzles
75~130
700
3
8 nozzles
90~150
4
Φ1200
6 nozzles
130~150
700
4.5
8 nozzles
150~180
5
Φ1600
6 nozzles
>150
700
7
8 nozzles
>180
8
